JSW Stud Rails are your choice for Quality, Service and Price!
One Stud Rail System.
Multiple Structural Applications.
JSW manufactures stud rail assemblies for column punching shear reinforcement and engineered applications at walls, mat and raft foundations, post-tension anchorage zones, and hold-down locations.
Custom rail configurations, pack assemblies, and tall-stud solutions are fabricated to the project’s approved structural details.
Applications & Configurations
Post-Tension Anchorage Zones
Stud rails for engineered anchorage-zone details
Explore PT Anchorage →Hold-Down Reinforcement
Rails coordinated with structural hold-down details
Explore Hold-Down Rails →Tall Stud Rails & Pack Assemblies
Extended-height and assembled rail configurations
Explore Tall Rails & Packs →
Evaluated Assemblies. Documented Manufacturing.
JSW Stud Rails are Type 1 headed shear stud assemblies that comply with ASTM A1044. ICC-ES ESR-3264 evaluates their use as punching shear reinforcement in flat concrete slabs.
JSW manufactures these assemblies under an approved quality-control program with third-party inspections by ICC-ES. Design and installation follow the applicable ACI 318 provisions identified in the report, its conditions of use, and approved project plans.
- Type 1 headed stud assemblies addressed in ESR-3264
- Stud spacing, height and rail length coordinated to project requirements
- Placing plans that identify rail locations and quantities
- Chairs and placement coordination for the specified cover
From takeoff to your jobsite.
Send your plans
Share structural drawings, specifications, addenda and bid dates.
Define the scope
Coordinate quantities, rail configurations and questions that need clarification.
Detail and prepare
Develop placing information and coordinate approved requirements for fabrication.
Deliver and support
Coordinate manufacturing, delivery and placement questions with your JSW team.
Start with the right information.
Can I request pricing from my own takeoff?
Yes. Download the Customer Stud Rail Pricing Form, fill in your quantities and dimensions, and return it with your project plans and requirements for JSW review.
Download Pricing FormWhat should I send for a stud rail takeoff?
Send the complete structural plan set, stud rail schedules, specifications and current addenda. Include the project location, bid date, anticipated deliveries and any scope exclusions.
Where can I find JSW's evaluation report?
The August 2026 ICC-ES ESR-3264 report is linked in Engineer Resources and Downloads. Review the report's scope, conditions and the project's applicable requirements.
Can JSW assist with placing plans?
Yes. JSW provides detailed placing plans and helps coordinate rail identification, locations and quantities for the project.
Submittals and Reports
Jobsite Stud Welding Flyer
Jobsite PSR overview
ESR-3264 - PSR Rail Assemblies
LA City Approval
LA City Fabricators License
LEED Scrap content - Recycled content
Let JSW offer our expertise in Stud Rails and show you why we are a leader in the industry.
ICC Approved Facilities ICC 3264
JSW meets ASTM A1044 at all locations
Manufactured in USA
Detailed placing plans
Quick manufacturing capabilities
